High Density Fiber Optic CS - MPO/MTP Breakout Cable Singlemode
MTP / MPO - CS Fanout Cable - Applications:
Asynchronous Transmission Mode(ATM)
Gigabit Ethernet
Active Deviced/Transceiver Interface
CATV, Video and Multimedia
Premise Installations
Telecommunication Networks
Parallel optical interconnect between PC Cards and patch panels
Interconnection for O/E modules
Industrial & Military
Optical Switch interframe connections
MTP / MPO - CS Fanout Cable - Features:
Precision molded MT ferrule
High precision guide pins for exact alignment
Compact design, up to 4,8,12,24 fibers
IEC 61754-7 Compliant
EIA/TIA-604-5 Compliant
MTP / MPO - CS Fanout Cable - Specifications:
| Item | LC,SC,ST,FC, CS....... | MPO/MTP |
| End face type | PC,UPC and APC | PC and APC |
| Fiber type | SM(G652,G655,G657)；MM(OM1-OM5) |
| Core number | 12,24 |
| Cable Diameter | 0.9,2.0,3.0 | Mini Round cable:Max4.5mm； Ribbon cable:Max3.0*5.0mm |
| Insertion loss(dB) | ≤ 0.3 | Standard:≤0.35/0.7(Typical/Max) Low Loss:≤0.2/0.35(Typical/Max) |
| Return loss(Min) | UPC SM:40dB APC SM:60 dB PC MM:25 dB | SM: APC:60dB | MM: PC:20dB |
| Test Wavelength (nm) | SM:1310/1550 MM:850/1300 |
| Repeatability | ≤ 0.1dB |
| Durability | ≤ 0.2dB |
| Interchangeability | ≤ 0.2dB |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -40℃~80℃ |
| Outer Sheath Material | PVC,LSZH |
| Bending radius (Static/Dynamic) | 10D/20D |
| Length | Customized |
MTP / MPO - CS Fanout Cable - Product Pictures:
MTP / MPO - CS Fanout Cable - Applications:
MTP / MPO - CS Fanout Cable - TAKFLY Overview
MTP / MPO - CS Fanout Cable - TAKFLY Services:
1.Order inquiry: Keep working 24 hours to gurantee the first reply to clients,no Cellphone power off all the day
2.Order production: Keep very close touch with production department to gurantee the right delivery time to clients
3.Before shipment: Our sales would double check the order quantity,package and strength of cartons to avoid lost and damage
4.After shipment: Keep tracking shipping status and reporting to clients
5.Shipment: DHL,UPS,FEDEX,TNT,EMS,SEA,AIR etc.
If you interest or have any question, Why not send inquiry? Welcome & Just Do It !!!
